Thermador columns and built-ins

01

Two columns joined is one installation, not two appliances

A refrigerator column and a freezer column butted together and joined with a trim kit behave as a single object. When the joint is out — because the floor is not level, because a panel is heavier than the hinge was set for, or because the kit was never fully tightened — the two doors stop sealing against each other along the shared edge.

What the owner sees is condensation down the seam, frost inside near the join, and a freezer running harder than it should. What it needs is a level, a shim and a hinge adjustment, and no part at all. It is the single most satisfying Thermador call there is, and the most frequently misdiagnosed.

02

Inside the column

Beyond alignment, the failures cluster in familiar places. Evaporator fans slow before they stop. Drain paths ice up at the trough and back the water into the compartment floor. The ice maker in a refrigerator column fails at the fill tube more often than at the module, because a tube that has frozen once will freeze again until the reason it froze is fixed.

Checked in this order on a column

• Door and trim alignment, top to bottom, before anything is opened
• Air path from the evaporator cover to the compartment vents
• Drain trough and the heater loop where the model has one
• Fill tube, inlet valve and water pressure at the appliance
• Fault codes the appliance is already holding, read from its own interface

03

Where it overlaps with the rest of the kitchen

Thermador, Bosch and Gaggenau share a great deal underneath. That is useful: parts availability is generally good, and a fault pattern seen on one shows up on the others. It is also a trap, because the panels, hinges and trim differ, and a hinge from a sibling brand will mount and then hold the door a degree off.
